Dual plunger series mode, floating piston design;
Advanced pump drive system, higher precision, better stability;
Electronic pulse compensation technology, multi-point flow correction, ensure accuracy, the range of flow
Velocity is more accurate, more stable operation and reliable performance, cost-effective;
Open computer control communication protocol, easy third party software control;
Time programmed man-machine conversation function;
State detection, fault warning, online help.
Network control to judge failure, and provide online solutions.
EMP0200 | SS316L | PEEK | PTFE |
Inlet port | 4mm | 4.76mm | |
Outlet port | 1/16 | 1/8 | |
Min flow set | 0.01mL/min | ||
Infusion way | Double plungers in parallel | ||
Flow rate range | (0～199.99)mL/min | ||
Max. working pressure | 20Mpa | 10Mpa | 4MPa |
Pressure pulsation | 1% | ||
Flow accuracy | ±0.5％ | ||
Flow stability(RSD) | 0.2% | 0.5% | |
Control mode | RS232 or LAN | ||
Display | 5.0-inch touch screen | ||
Overall dimension | 368*260*140（L*W*H） | ||
Power | 150W | ||
Weight | 8.5kg | ||
