Dual plunger series mode, floating piston design;
Advanced pump drive system, higher precision, better stability;
Electronic pulse compensation technology, multi-point flow correction, ensure accuracy, the range of flow
Velocity is more accurate, more stable operation and reliable performance, cost-effective;
Open computer control communication protocol, easy third party software control;
Time programmed man-machine conversation function;
State detection, fault warning, online help.
Network control to judge failure, and provide online solutions.
EMP050 | SS316L | Hastelloy | PEEK | PTFE |
Inlet port | 1/8 | |||
Outlet port | 1/16 | |||
Infusion way | Double pistons in series model | |||
Min flow set | 0.001mL/min | |||
Flow rate range | (0~49.999)mL/min | |||
Max. working pressure | 30Mpa | 15Mpa | 4Mpa | |
Pressure pulsation | 0.5%, at 10Mpa | |||
Flow accuracy | ±0.15% | ±0.5% | ||
Flow stability(RSD) | 0.1% | 0.5% | ||
Control mode | RS232 or LAN | |||
Display | 5.0-inch touch screen | |||
Overall dimension | 368*260*140(L*W*H) | |||
Power | 150W | |||
Weight | 6.9kg | |||
