50ml High Pressure Infusion Pump

  • Dual plunger series mode, floating piston design;

  • Advanced pump drive system, higher precision, better stability;

  • Electronic pulse compensation technology, multi-point flow correction, ensure accuracy, the range of flow

  • Velocity is more accurate, more stable operation and reliable performance, cost-effective;

  • Open computer control communication protocol, easy third party software control;



  • Time programmed man-machine conversation function;

  • State detection, fault warning, online help.

  • Network control to judge failure, and provide online solutions.

EMP050
SS316L
Hastelloy
PEEK
PTFE
Inlet port
1/8
Outlet port
1/16
Infusion way
Double pistons in series model
Min flow set
0.001mL/min
Flow rate range
(0~49.999)mL/min
Max. working pressure
30Mpa
15Mpa
4Mpa
Pressure pulsation
0.5%, at 10Mpa
Flow accuracy
±0.15%
±0.5%
Flow stability(RSD)
0.1%
0.5%
Control mode
RS232 or LAN
Display
5.0-inch touch screen
Overall dimension
368*260*140(L*W*H)
Power
150W
Weight
6.9kg
